→Technoplat CS and CW are automatic wrapping machines and represent the innovative solution to fully automatic pallet wrapping.
The machine is equipped with the Film Clamp and Cut unit with spreader, in the CS version, and welder, in the CW version, which ensures the film tail is attached, cut, spread or welder and perfectly adhered to the pallet.
Benefit
| Turntable diameter | mm | 1650 std. 1800 opt. |
| Max load weight | kg | 2000 std. 2500 opt. |
| Turntable speed | rpm | 5÷12 |
| Carriage up-down speed | m/min | 1,5÷5,5 |
| Maximum product dimensions (LxW) | mm | 1000×1200 std. 1200×1200 opt. |
| Maximum product height | mm | 2200 std. 2400/2800/3100 opt. |
| Film carriage type | FR, PDS, PVS | |
| Film stretch | adjustable from panel | |
| Film pre-stretch | n.a. (FR), fixed 250% std (PDS), variable 150-400% (PVS) | |
| Forklifting | front and rear | |
| Power supply voltage | V | 230 V 1Ph |
| Power supply frequency | Hz | 50/60 |
| Installed power | kW | 2,1÷2,9 |
| Max reel dimensions | mm | 500×300 |
| Max reel weight | kg | 20 |
| Film thickness | μm | 17÷35 |
